Sarca Excel Anchor Dimensions

Calibrated Anchor Chain – General Information

Calibrated means that each link is manufactured to the same dimensions within a given tolerance. Windlass gypsys are generally designed and manufactured to be compatible with a given size and calibration of chain. When the dimensions are close but not a direct match, it can be difficult to detect without a practical trial. The problem … Continued

Read more

Calibrated Anchor Chain Quality Control

World renowned chain manufacturers Jimmy Green Marine policy is to purchase G3 Grade 40, G6, G6+ and Grade 70 calibrated chain from world renowned brands and manufacturers: MF Catenificio Frigerio, Lofrans, Titan, cromox and William Hackett Ltd. Accountability Every single length of chain purchased by Jimmy Green Marine is marked and recorded with the supplier, … Continued

Read more

AQUA4 Calibrated Anchor Chain – Dimensions | Jimmy Green Marine

6mm DIN766 = 6mm Diameter x 18.5mm Pitch 7mm DIN766 = 7mm Diameter x 21mm Pitch 8mm DIN766 = 8mm Diameter x 24mm Pitch 10mm DIN766 = 10mm Diameter x 28mm Pitch 10mm ISO4565 = 10mm Diameter x 30mm Pitch 12mm ISO4565 = 12mm diameter x 36mm Pitch 13mm DIN766 = 13mm diameter x 36mm Pitch 14mm DIN766 … Continued

Read more

AQUA4 – USA Dimensions and Load Limits

AQUA4 USA Calibration Dimensions and Load Limits Size Diameter mm Inside Length Inside Width Working Load Breaking Load Grade Pitch mm mm Kg KN 5/16″ 8.7 26.1 12.2 1769 52 43 3/8″ 10.3 31 14.5 2450 72 43 1/2″ 13.5 40.4 22.9 4173 122 43 AQUA7 USA Calibration Dimensions and Load Limits Size Diameter mm … Continued

Read more
